  Xactics 2001 International Inc. (Canada)
  Inquiry
    2501

  • Rigid polyurethane foam insulation is more than 8 cm thick
  • Insulated excellent performance
    (dry ice loss 5% / 24 Hr)
  • Tiered performance with high intensity
  • Long-term protection from UV rays
  • Considering the safety of the fastener does not adopt a protrusion
  • Structure can be cleaned (drain plug with O-ring) in the sanitary
  • To be made of polyethylene, is rust.
  • Built-in palettes (4 direction from the insert)
  • Standard Color: Gray (other colors accepted by Lott)


    1001


 Dry ice, ice, ice cream, bread dough, flowers, frozen foods, meat and fish are sensitive to temperature changes and other products and materials can be used for storage and logistics.




    Covered in   1001/1401 Caster units

  (78K)
Model No. 1001 1401 2501 3201 3503
External
size
Width (mm) 1070 1230 1220 1220 1220
Depth (mm) 610 720 1090 1090 1085
Height (mm) 710 840 915 1035 1190
Inside
dimension
Width (mm) 940 1080 1055 1055 1060
Depth (mm) 510 580 965 965 965
Height (mm) 560 640 710 810 995
Weight         (kg) 49 64 64 70 91.5
Volume         (L) 283 400 700 850 1000
Content
(Dry ice)
Block(kg) - 400 600 900 900
Pellet(kg) 230 320 530 640 700
You can download
the pamphlet from here.→
Head insulation container 1001 pamphlet(PDF)
(80K)
Head insulation container 1401 pamphlet(PDF)
(80K)
- - -


Detailed Description (PDF Files) to view Adobe Reader is required.
Acrobat Reader download If your computer has not been introduced, the banner on the left for free from Adobe's site can be downloaded.
